Description
The Molex 2.5mm Dupont Female to Male Pre-Crimped Terminal Silicone Cable offers a reliable and flexible connection solution for various electrical applications. Designed with 22AWG UL3239 soft wire, this cable provides excellent flexibility and high-temperature resistance, perfect for industrial, automotive, and robotics applications. Its silicone insulation is rated to withstand temperatures of up to 200℃, making it highly heat-resistant and suitable for high-performance systems. With a voltage rating of 3KV and a current rating of 3A, it ensures stable and secure power transmission. The pre-crimped terminals eliminate the need for additional connectors, streamlining installation and making it convenient for your projects.
| Key Features |
| Female to Male Dupont Cable: This cable offers a female-to-male connection, making it ideal for extending circuits or connecting components with standard Dupont connectors. |
| Pre-Crimped Terminals: The cable comes with pre-crimped terminals, reducing installation time and ensuring a reliable and secure connection. |
| 22AWG UL3239 Soft Wire: The 22AWG UL3239 soft wire is flexible, durable, and ideal for high-temperature applications, providing reliable electrical performance. |
| 200℃ Heat-Resistant Silicone Insulation: The silicone insulation is capable of withstanding up to 200℃, making it perfect for high-temperature environments. |
| 3KV Voltage Rating & 3A Current Rating: This cable supports 3KV voltage and 3A current, ensuring safe and efficient power delivery for various projects. |
| Highly Flexible & Durable: The silicone jacket enhances flexibility and durability, making the cable reliable in both static and dynamic applications. |
| Wide Application Range: Suitable for a wide range of applications, including robotics, automotive, electronics, and high-temperature environments. |
| Technical Specifications |
| Connector Type: Female to Male Dupont Pre-Crimped Terminals (Without Connectors) |
| Pitch: 2.5mm (Compatible with Molex 2.5mm Dupont Connectors) |
| Wire Gauge: 22AWG |
| Insulation Material: UL3239 Silicone |
| Rated Temperature: Up to 200℃ |
| Voltage Rating: 3KV |
| Current Rating: 3A |
| Conductor Material: Tinned Copper |
| Wire Length: Customizable lengths available |
| Applications: Robotics, automotive, industrial systems, and high-temperature applications. |
| Why Choose This Product? |
| Exceptional Heat Resistance: The silicone insulation ensures that the cable can withstand temperatures up to 200℃, making it suitable for high-heat environments. |
| Pre-Crimped Terminals for Easy Installation: The cable comes with pre-crimped terminals, which saves you time and simplifies the process of making connections. |
| Flexible & Durable: The silicone jacket provides both flexibility and long-lasting durability, even in challenging applications. |
| High Voltage & Current Rating: With a 3KV voltage rating and 3A current rating, this cable is perfect for projects requiring stable power transmission and safety. |
Additional information
| Weight | 0.1 kg |
|---|---|
| Dimensions | 15 × 15 × 2 cm |
| Color |
Red ,Black ,Yellow ,White ,Blue ,Green ,Orange ,Purple ,Brown ,Grey |
| Sided |
Female Single Sided ,Male Single Sided ,Male-Female Extension |
| Length |
100mm ,150mm ,200mm ,250mm ,300mm ,350mm ,400mm ,500mm ,800mm ,1000mm |
Reviews (0)
You must be logged in to post a review.
Shipping & Delivery
Molex 2.5mm Dupont Female to Male Pre-Crimped Terminal Silicone Cable (Without Connector), 22AWG UL3239 Soft Wire 200℃ Heat Resistant 3KV 3A
Price range: $0.34 through $2.00
Molex 2.5mm Dupont female to male pre-crimped terminal silicone cable, 22AWG UL3239 soft wire, heat-resistant up to 200℃, 3KV, 3A, perfect for high-temperature, flexible, and durable electrical connections.
